This 2.5mm² SDI cable is a sheathed, double insulated single core cable supplied on a 100 metre roll. With red insulation under a white outer sheath, it is used as an active conductor for power circuits, switchboard wiring and runs where a separately sheathed single core is preferred.

A 7/0.67mm stranded copper conductor is insulated in V-90 PVC and protected by a 3V-90 PVC sheath, giving a cable of about 5.2mm diameter rated 450/750V. The cable is metre marked for easy measuring and is rated at 23A unenclosed touching, 12A surrounded by thermal insulation and 33A buried in ducts.

Key Features

  • 2.5mm² Conductor – A common size for power circuit actives.
  • Double Insulated – Red V-90 insulation plus a white 3V-90 outer sheath.
  • Red Active Colour – Clearly identifies the conductor as an active.
  • Stranded Copper – 7/0.67mm conductor that bends and terminates easily.
  • 450/750V Rating – Suits general low-voltage building wiring.
  • 90°C Rated – V-90 insulation for a 90°C maximum conductor temperature.
  • Metre Marked – Accurate measuring on site.
  • 100m Roll – Plenty of cable for multiple circuits.

Specifications

  • Conductor Size: 2.5mm²
  • Cores: Single core (active)
  • Conductor: Plain annealed copper, stranded 7/0.67mm
  • Insulation: V-90 PVC
  • Insulation Colour: Red
  • Sheath: 3V-90 PVC
  • Sheath Colour: White
  • Overall Diameter: 5.2mm (±10%)
  • Max Conductor Temperature: 90°C
  • Voltage Rating: 450/750V
  • Standard: AS/NZS 5000.2
  • Current Rating: 23A unenclosed touching / 12A surrounded by thermal insulation / 33A buried in ducts
  • Marking: Metre marked
  • Length: 100m roll

Applications

  • Active conductors for power circuits run as single cores
  • Switchboard and meter panel wiring
  • Circuits run in conduit where a sheathed single core is preferred

The 2.5mm² SDI Red 100 metre roll pairs a stranded copper conductor with red V-90 insulation and a white sheath, giving a clearly identified, double insulated active for everyday power and switchboard wiring.

Q. What does SDI mean?
A.
SDI stands for sheathed double insulated. The conductor has its own coloured insulation plus a separate outer sheath.

Q. Is a black version available?
A.
Yes. We also stock 2.5mm SDI in black, typically used for neutral conductors.

Q. What is the current rating of 2.5mm SDI?
A.
It is rated at 23A unenclosed touching, 12A surrounded by thermal insulation and 33A buried in ducts. The final rating depends on the installation method and derating under AS/NZS 3008.1.1.

Q. How long is the roll?
A.
This listing is a 100 metre roll of 2.5mm² red SDI.
