This 2.5mm² Twin Active TPS cable is a flat cable with red and white cores, both used as active conductors, supplied on a 100 metre roll. It is commonly used for switched and two-way circuits, and for installations that need two separately switched actives in one cable.

The two 7/0.67mm stranded copper cores are insulated with V-90 PVC and enclosed in a 3V-90 PVC sheath, giving a flat cable of about 8.9 x 5.5mm. Rated 450/750V with a 90°C maximum conductor temperature, it is metre marked for easy measuring on site.

Key Features

  • Two Active Cores – Red and white cores, both used as actives.
  • 2.5mm² Conductors – Suits power and heavier switched circuits.
  • Stranded Copper – 7/0.67mm construction for flexibility and easy termination.
  • V-90 PVC Insulation – Rated for a 90°C maximum conductor temperature.
  • 3V-90 PVC Sheath – Durable outer sheath for building wiring.
  • 450/750V Rating – Suits standard 230V installations.
  • Flat Profile – Easy to run and clip along framing and in wall cavities.
  • Metre Marked – Measure runs quickly and track remaining cable.

Specifications

  • Conductor Size: 2.5mm²
  • Cores: Two actives
  • Conductor: Plain annealed copper, stranded 7/0.67mm
  • Core Colours: Red and white (actives)
  • Insulation: V-90 PVC
  • Sheath: 3V-90 PVC
  • Overall Dimensions: 8.9 x 5.5mm
  • Max Conductor Temperature: 90°C
  • Voltage Rating: 450/750V
  • Standard: AS/NZS 5000.2
  • Marking: Metre marked
  • Length: 100m roll

Applications

  • Switch loops and two-way switching circuits
  • Separately switched circuits needing two actives in one cable
  • Residential and commercial building wiring

The 2.5mm² Twin Active TPS 100m roll combines red and white stranded copper actives, V-90 insulation and a 450/750V rating in a metre-marked flat cable for switching and control work.

Q. What is twin active cable used for?
A. Twin active cable has two cores that are both used as actives, commonly for switch loops, two-way switching and separately switched circuits.

Q. What colours are the cores?
A. The cores are red and white. A blue/white 2.5mm twin active is also available.

Q. Does it include an earth?
A. No. For circuits that need an earth in the same cable, choose 2.5mm Twin and Earth, sold on 100m rolls or per metre.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.
