The 3A Lighting ATLAS 4 (DL1570-SCTC13S02) is a versatile and stylish 13W LED downlight kit, offering a high-efficiency lighting solution for residential and commercial applications. Featuring triac dimming, a recessed anti-glare diffuser, and selectable colour temperatures, it delivers superior performance with modern aesthetics. The silver housing provides a contemporary finish, ideal for spaces where visual appeal and functionality are equally important.

With an IP54 rating, wide 100° beam angle, and flicker-free driver, the ATLAS 4 is suitable for a wide range of indoor environments, including damp areas such as bathrooms or covered outdoor settings.

Key Features

Triac Dimmable – Smooth dimming control compatible with standard wall dimmers
Selectable Colour Temperature – Adjustable between 3000K, 4000K, and 5000K for maximum flexibility
High Lumen Output – Delivers up to 900 lumens with excellent energy efficiency
IP54 Rated – Suitable for damp or semi-outdoor areas like bathrooms or covered patios
Anti-Glare Diffuser – Recessed design; Soft, comfortable light distribution with reduced eye strain
Wide 100° Beam Angle – Broad, even light spread ideal for general lighting applications
Sleek Silver Finish – Modern appearance to complement contemporary interiors
IC-4 Rated – Safe for direct installation under insulation in accordance with Australian standards

Specifications

Model: DL1570-SCTC13S02
Power Consumption: 13W
Input Voltage: 220–240V AC, 50/60Hz
Colour Temperatures: 3000K / 4000K / 5000K (selectable)
Lumen Output: 900 lm
CRI: >80 (Ra)
Beam Angle: 100°
IP Rating: IP54
Cut-Out Size: Ø90 - 100 mm
Fitting Dimensions: Ø110 mm × 49.7 mm depth
Light Source: Bridgelux SMD LED
Housing Colour: Silver
Dimming: Triac compatible
Rating: IC-4 compliant

Applications

General ceiling lighting for homes, apartments, and commercial spaces
Kitchens, living areas, hallways, and bedrooms
Bathrooms and semi-outdoor zones (covered patios, eaves)
Retail shops, cafés, galleries, and hospitality venues
Installations requiring adjustable colour temperatures and dimmable lighting

Combining flexibility, performance, and a sleek silver finish, the 3A Lighting ATLAS 4 13W LED Downlight Kit is a premium choice for modern lighting installations. Its wide beam, selectable colour temperatures, and energy-efficient design make it perfect for both new builds and retrofits.

Q. Can I change the colour temperature of this downlight?
A. Yes, the DL1570-SCTC13S02 allows you to select from 3 colour temperatures: 3000K, 4000K, 5000K

Q. Is this downlight dimmable?
A. Yes, it features Triac dimming, compatible with leading and trailing-edge dimmer switches.

Q. What is the recommended cut-out size?
A. The recommended cut-out size is 90–100 mm, with an overall fitting diameter of 110 mm.

Q. Can I use this in a bathroom ceiling?
A. Yes, the IP54 rating makes it suitable for damp areas like bathrooms and laundry rooms.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Complete Kit Includes: LED Light Fitting, LED Driver and 2 Pin Flex & Plug
13W High Quality SMD LED Chip
High Quality 270maH Driver
Recessed Style Fixed White Fitting
IC-F Abutted & Covered Rating (you can cover the downlight with insulation, the LED driver sits ontop of insulation)
Tri Colour - Choose between Warm White (3000K), Cool White (4000K) and Daylight (5700K) before you install the downlight!
850lm (Warm White), 880lm (Cool White), 900lm (Daylight)
Dimmable LED Driver with Flex & Plug
Compatible with major leading and trailing edge dimmers.
90-95mm Cut Out diamtere
104mm total diameter
90 Degree Beam Angle
Frosted Diffuser (cant see the LED chips inside)
Only 30mm height clearance required
SAA Approved
3 Years Replacement Warranty

Specifications

Colour	Brushed Silver
Type	LED Downlight
Wattage	13W
Voltage	200-240V AC
Installation Area	Indoor
IP Rating	IP54
Colour Temperature	Tri Colour
Lighting Technology	LED
Lumens	900lm
PRODUCT INFO
SKU	DL13W-SR3
Model #	DL1570-SCTC13S02
Barcode #	9360338007647
Brand	3A
SHIPPING INFO
Shipping Weight	0.4000kg
Shipping Width	0.115m
Shipping Height	0.090m
Shipping Length	0.115m
