Need just enough three-phase cable for one job? This 6.0mm² 4 Core + Earth Orange Circular cable comes cut to the metre, letting you order the exact length for a submain, machine supply or three-phase outlet circuit without buying a whole roll.

Inside the hard-wearing orange 5V-90 PVC sheath are four V-90 PVC insulated cores in red, white, blue and black, plus a green/yellow earth. With a nominal diameter of about 15mm and a 450/750V rating at a 90°C maximum conductor temperature, it glands neatly into switchboards and equipment and draws easily through conduit. Electricians and maintenance teams rely on it for one-off three-phase runs, repairs and equipment connections where a full roll would be wasted.

Key Features

  • Sold by the Metre – Buy only the length the circuit needs, ideal for single runs and repairs.
  • Three-Phase Ready – Four cores plus earth cover three actives and a neutral in one cable.
  • 6.0mm² Cores – A capable size for moderate three-phase loads and small submains.
  • 90°C V-90 Insulation – PVC insulation on every core, rated for a 90°C conductor temperature.
  • Easy Phase Identification – Red, white, blue and black cores with a green/yellow earth.
  • 450/750V Rated – Suits standard 230/400V low-voltage installations.
  • Robust Orange Sheath – An orange 5V-90 PVC outer layer that stands up to handling on site.
  • Gland-Friendly Round Build – An approximately 15mm circular profile for secure gland sealing.

Specifications

  • Model: OC604CE
  • Conductor Size: 6.0mm²
  • Cores: 4 cores + earth
  • Conductor: Plain annealed copper
  • Core Colours: Red, white, blue, black and green/yellow
  • Insulation: V-90 PVC
  • Sheath: 5V-90 PVC
  • Sheath Colour: Orange
  • Overall Diameter: 15.0mm (±10%)
  • Max Conductor Temperature: 90°C
  • Voltage Rating: 450/750V
  • Standard: AS/NZS 5000.2
  • Length: Sold per metre

Applications

  • Single three-phase runs to machinery, pumps and compressors
  • Short three-phase submains to sheds and workshop boards
  • Maintenance repairs and replacement of damaged three-phase cable

Sold per metre, the OC604CE 6.0mm² 4 Core + Earth Orange Circular delivers V-90 insulated, colour-coded cores in a tough 450/750V orange sheath without the commitment of a full roll. It is the practical way to buy three-phase cable for one-off jobs and repairs.

Q. How much cable do I get per unit?
A. Each unit is one metre, so the quantity you enter is the length you will receive. If you need a full drum, the same cable is also listed as 100m and 500m rolls.

Q. Is this the same cable as the 6.0mm 4C+E 100m roll?
A. Yes. It is the same 6.0mm² 4 Core + Earth orange circular cable, simply sold by the metre instead of as a full roll.

Q. What is the overall diameter for gland selection?
A. The nominal overall diameter is about 15.0mm (±10%). Measure the cable or allow for this tolerance when choosing glands and conduit.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.
