The Clipsal 56 Series 3 Pin 15A Appliance Inlet in Grey (56AI315-GY) is a weatherproof, surface mounted inlet for feeding 15A power into equipment or a building through a lead. It suits 3 flat pin connections rated 15A at 250V.

Rated IP66, its downward facing, angled pin housing lets the extension socket connect neatly without bulky right angle entry. A screwed lock ring comes standard to secure the extension socket and help keep the IP rating.

Key Features

  • 15A Inlet – 3 flat pin, 1P+N+E.
  • IP66 Weatherproof – Protected against dust and powerful water jets.
  • Angled Pin Housing – Downward facing for neat connections.
  • Screwed Lock Ring – Secures the connector and supports IP66.
  • No Reverse Pin Plugs – Mates with 56CSC extension sockets.
  • Surface Mounted – Fixes directly to walls or equipment.
  • Screw Terminals – Accept 2.5 to 6mm² conductors.
  • Polycarbonate Cover – Tough, impact resistant cover.
  • 56 Series Range – Part of Clipsal's 56 Series weatherproof family.

Specifications

  • Model: 56AI315-GY
  • Range: Clipsal 56 Series
  • Type: Appliance inlet
  • Pins: 3 flat
  • Poles: 1P+N+E
  • Rated Current: 15A
  • Rated Voltage: 250V AC
  • IP Rating: IP66
  • Terminals: Screw, 2.5–6mm²
  • Mating Connector: 56CSC315 extension socket
  • Dimensions: 107 x 101 x 82mm
  • Colour: Grey

Applications

  • Generator and temporary power connection points
  • Machinery and equipment power inlets
  • Workshops, farms and outdoor sites

Bring 15A power in safely with the Clipsal 56AI315-GY IP66 appliance inlet.

Q. What is the Clipsal 56AI315-GY used for?
A. It is an appliance inlet, letting power be fed in through a lead fitted with a matching extension socket.

Q. What connector suits the Clipsal 56AI315-GY?
A. It mates with the Clipsal 56CSC315 15A extension socket. No special reverse pin plug is needed.

Q. Is the Clipsal 56AI315-GY weatherproof?
A. Yes. It is rated IP66, and the screwed lock ring helps maintain the rating.

Q. What cable sizes suit the Clipsal 56AI315-GY?
A. Screw terminals accept 2.5 to 6mm² conductors.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Amp 15A
Colour Grey
Type Appliance Inlet
IP Rating IP66
Material Plastic, Polycarbonate (Cover)
Frequency 50Hz
Standard AS/NZS 60320.1
Poles 1P + N + E
Range Clipsal 56 Series
Pin Number 3 Pins
Shape Of Pin Flat
PRODUCT INFO
SKU CL56AI315-GY
Model # 56AI315-GY
Barcode # 9311554202828
Brand Clipsal
SHIPPING INFO
Shipping Weight 0.4160kg
Shipping Width 0.106m
Shipping Height 0.092m
Shipping Length 0.110m
