The Clipsal 56 Series 3 Flat Pin 15A RCD Protected Switched Socket Outlet in Grey (56C315RC-GY) combines a switched socket outlet with a built in 30mA residual current device, rated 15A at 250V AC for 1 phase supplies. It accepts the matching Clipsal 56P315 plug.

Part of Clipsal's 56 Series weatherproof family. The 2 gang surface unit is rated IP66, mounts vertically and has a Class A earth leakage device with a push-button control. It has a polycarbonate housing, a protective cover over the outlet and screw terminals for 1 to 6mm² cable, with Class II insulation. It measures 204 x 101 x 102mm and is finished in grey (RAL 7035).

Key Features

  • 15A, 250V – Rated 15A at 250V AC, 50Hz.
  • 30mA RCD Protection – Built in earth leakage protection.
  • Class A RCD – Clipsal earth leakage class A.
  • Push-Button Control – Push-button RCD control.
  • 3 Flat Pins – 1 phase outlet.
  • IP66 Weatherproof – Protected against dust and powerful water jets.
  • Protective Cover – Cover over the socket outlet.
  • Screw Terminals – Accept 1 to 6mm² cable.
  • Matching Plug – Accepts the 56 Series 56P315 plug.
  • 56 Series Range – Part of Clipsal's 56 Series weatherproof family.

Specifications

  • Model: 56C315RC-GY
  • Range: Clipsal 56 Series
  • Type: RCD protected switched socket outlet, polycarbonate
  • Rated Current: 15A
  • Rated Voltage: 250V AC, 50Hz
  • Phases: 1 phase
  • Pins: 3 flat pins
  • RCD: 30mA, Class A, push-button
  • Gangs: 2
  • Terminals: 1 to 6mm²
  • IP Rating: IP66
  • Orientation: Vertical
  • Matching Plug: 56P315
  • Colour: Grey
  • Dimensions: 204mm H x 101mm W x 102mm D

Applications

  • 15A tools, pumps and equipment
  • Outdoor and wet areas
  • Workshops and commercial sites

Add earth leakage protection right at the outlet with the Clipsal 56C315RC-GY RCD protected switched socket.

Q. What RCD protection does the Clipsal 56C315RC-GY have?
A.
It has a built in 30mA Class A residual current device with push-button control.

Q. What is the Clipsal 56C315RC-GY rated?
A.
It is rated 15A at 250V AC for 1 phase supplies.

Q. What plug suits the Clipsal 56C315RC-GY?
A.
It accepts the matching 56 Series 56P315 plug (3 flat pins).

Q. Is the Clipsal 56C315RC-GY weatherproof?
A.
Yes. It is rated IP66 against dust and powerful water jets when correctly installed.

Q. What size is the Clipsal 56C315RC-GY?
A.
It is a 2 gang unit measuring 204mm high x 101mm wide x 102mm deep, mounted vertically.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Amp 15A
Colour Grey
Type Socket Outlet with Residual Current Device
IP Rating IP66
Material Polycarbonate
Frequency 50Hz
Range Clipsal 56 Series
Pin Number 3 Pins
Shape Of Pin Flat
PRODUCT INFO
SKU CL56C315RC-GY
Model # 56C315RC-GY
Barcode # 9311554276904
Brand Clipsal
SHIPPING INFO
Shipping Weight 1.0060kg
Shipping Width 0.108m
Shipping Height 0.116m
Shipping Length 0.208m
