The Clipsal 56 Series Surface Socket, 20A 500V, 4 Round Pins (56SO420-GY) is an IP66 weatherproof socket outlet for surface mounting. It is a 3 phase outlet (3P+E) rated 20A at 500V AC, and accepts the matching 56P420 plug.

Part of Clipsal's 56 Series weatherproof family. It has brass terminal screws that take 2.5 to 6mm² rigid or stranded cable, and is finished in grey (RAL 7035). The hoseproof, dust resistant flap closes with an automatic snap catch latch, and the transparent flap allows a quick visual check of the socket and pin configuration.

Key Features

  • IP66 Rated – Weatherproof for wet and dusty areas.
  • 20A, 500V – Rated 20A at 500V AC 50Hz.
  • 4 Round Pins – 3P+E configuration.
  • Matching Plug – Accepts the 56 Series 56P420 plug.
  • Transparent Flap – Quick visual check of socket and pins.
  • Snap Catch Latch – Flap closes automatically.
  • Brass Terminal Screws – Take 2.5 to 6mm² cable.
  • Surface Mounting – Fixes directly to the wall or panel.
  • Grey Finish – RAL 7035 industrial grey.
  • 56 Series Range – Matches Clipsal 56 Series plugs and accessories.

Specifications

  • Model: 56SO420-GY
  • Range: Clipsal 56 Series
  • Type: Surface socket outlet
  • Rated Current: 20A
  • Rated Voltage: 500V AC, 50Hz
  • Pins: 4, round
  • Poles: 3P+E
  • Terminals: Brass screws, 2.5 to 6mm²
  • Protection: IP66
  • Mounting: Surface
  • Colour: Grey (RAL 7035)
  • Dimensions: 107mm H x 101mm W x 102mm D

Applications

  • 3 phase power for workshops and sheds
  • Washdown and wet areas
  • Industrial and agricultural sites

Supply 3 phase power in harsh conditions with the Clipsal 56SO420-GY IP66 surface socket.

Q. What plug suits the Clipsal 56SO420-GY?
A. It accepts the matching 56 Series 56P420 plug (4 round pin).

Q. What is the Clipsal 56SO420-GY rated?
A. It is rated 20A at 500V AC, 3P+E, with IP66 protection.

Q. What cable does the Clipsal 56SO420-GY take?
A. The brass screw terminals take 2.5 to 6mm² rigid or stranded cable.

Q. What size is the Clipsal 56SO420-GY?
A. It measures 107mm high x 101mm wide x 102mm deep.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Amp 20A
Colour Grey
Type Socket Outlet
Voltage 500V AC
Material Polycarbonate (Cover)
Frequency 50Hz
Standard AS/NZS 3112
Poles 3P + E
Range Clipsal 56 Series
Pin Number 4 Pins
Shape Of Pin Round
PRODUCT INFO
SKU CL56SO420-GY
Model # 56SO420-GY
Barcode # 9311554203658
Brand Clipsal
SHIPPING INFO
Shipping Weight 0.5460kg
Shipping Width 0.108m
Shipping Height 0.114m
Shipping Length 0.110m
