The Clipsal 56 Series 5 Round Pin 20A Cord Extension Socket in Electric Orange (56CSC520-EO) is an in-line socket for making up 20A extension leads, rated 20A at 500V AC with 5 round pins (3P+N+E). Clipsal designs it as a common unit for both cord extension socket and appliance connector use.

Part of Clipsal's 56 Series weatherproof family. It has brass contact sleeves, screw terminals for 1 to 6mm² conductors and an M25 cable gland for 7 to 16mm cable. The impact resistant, UV stabilised moulding is finished in Electric Orange (RAL 2004). The IP66 rating is achieved when it is used with compatible accessories such as the matching 56P520 plug or a 56AI appliance inlet. Cable is not included.

Key Features

  • 20A, 500V – Rated 20A at 500V AC, 50Hz.
  • 5 Round Pins – 3P+N+E configuration.
  • Extension Socket – In-line socket for extension leads.
  • Appliance Connector – Same unit suits appliance connector use.
  • IP66 When Mated – With compatible 56 Series accessories.
  • Matching Plug – Mates with the 56 Series 56P520 plug.
  • 56AI Compatible – Connects to 56 Series appliance inlets.
  • Cable Gland – M25 gland for 7 to 16mm cable.
  • Brass Sleeves – Screw terminals take 1 to 6mm².
  • 56 Series Range – Part of Clipsal's 56 Series weatherproof family.

Specifications

  • Model: 56CSC520-EO
  • Range: Clipsal 56 Series
  • Type: Cord extension socket
  • Rated Current: 20A
  • Rated Voltage: 500V AC, 50Hz
  • Pins: 5, round (3P+N+E)
  • Terminals: 1 to 6mm²
  • Cable Diameter: 7 to 16mm
  • Cable Gland: M25
  • IP Rating: IP66 (with compatible accessories)
  • Matching Plug: 56P520
  • Colour: Electric Orange (RAL 2004)

Applications

  • 3 phase power for machinery and workshops
  • Construction sites and portable power
  • Industrial and agricultural sites

Make up a tough 20A extension lead with the Clipsal 56CSC520-EO 56 Series extension socket.

Q. What plug fits the Clipsal 56CSC520-EO?
A. It mates with the matching 56 Series 56P520 plug, and it connects to 56AI appliance inlets.

Q. What is the Clipsal 56CSC520-EO rated?
A. It is rated 20A at 500V AC, 3P+N+E.

Q. What cable suits the Clipsal 56CSC520-EO?
A. The terminals take 1 to 6mm² conductors, and the M25 gland suits 7 to 16mm cable. Cable is not included.

Q. Is the Clipsal 56CSC520-EO weatherproof?
A. It is rated IP66 when used with compatible 56 Series accessories, such as the 56P520 plug.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Amp 20A
Colour Electric Orange
Type Extension Socket
Voltage 500V AC
IP Rating IP66
Material Polycarbonate (Housing)
Frequency 50Hz
Standard AS/NZS 3120
Poles 3P + N + E
Range Clipsal 56 Series
Pin Number 5 Pins
Shape Of Pin Round
