The Clipsal 56 Series Socket Outlet, 32A 500V, 5 Round Pins, Less Enclosure (56SO532LE-GY) is a 3 phase socket outlet with 5 round pins (3P+N+E), rated 32A at 500V AC. It is the Less Enclosure (LE) base version, so the surface enclosure is not included. It accepts the matching Clipsal 56P532 plug.

Part of Clipsal's 56 Series weatherproof family. It has brass terminal screws that take 4 to 16mm² rigid or stranded cable, tightened to 0.8 N.m, and measures 107 x 101 x 74mm. The finish is grey (RAL 7035). Clipsal 56 Series sockets have a hoseproof, dust resistant flap with an automatic snap catch latch, and the transparent flap allows a quick visual check of the socket and pin configuration.

Key Features

  • 32A, 500V – Rated 32A at 500V AC, 50Hz.
  • 5 Round Pins – 3P+N+E configuration.
  • Less Enclosure – Base version, enclosure not included.
  • Matching Plug – Accepts the 56 Series 56P532 plug.
  • Transparent Flap – Quick visual check of socket and pins.
  • Snap Catch Latch – Flap closes automatically.
  • Brass Terminal Screws – Take 4 to 16mm² cable.
  • 56 Series Range – Matches Clipsal 56 Series plugs and accessories.

Specifications

  • Model: 56SO532LE-GY
  • Range: Clipsal 56 Series
  • Type: Surface socket outlet, less enclosure
  • Rated Current: 32A
  • Rated Voltage: 500V AC, 50Hz
  • Pins: 5 round pins
  • Poles: 3P+N+E
  • Terminals: Brass screws, 4 to 16mm²
  • Matching Plug: 56P532
  • Colour: Grey (RAL 7035)
  • Dimensions: 107mm H x 101mm W x 74mm D

Applications

  • 3 phase power for machinery and workshops
  • Construction sites and portable power
  • Industrial and agricultural sites

Replace or build a 56 Series 32A outlet with the Clipsal 56SO532LE-GY less enclosure socket.

Q. What plug suits the Clipsal 56SO532LE-GY?
A. It accepts the matching 56 Series 56P532 plug.

Q. What is the Clipsal 56SO532LE-GY rated?
A. It is rated 32A at 500V AC, 3P+N+E.

Q. Does the Clipsal 56SO532LE-GY include an enclosure?
A. No. It is the less enclosure (LE) base version, measuring 107 x 101 x 74mm.

Q. What cable does the Clipsal 56SO532LE-GY take?
A. The brass screw terminals take 4 to 16mm² rigid or stranded cable.

All products must be installed by a licensed electrican. DIY electrical work is illegal and very dangerous.

Change of Mind
All products purchased from MJS Electrical Products & Supplies are backed by a thirty (30) day Peace of Mind Return Policy. All products returned must be in perfect unused condition, with all components, complete with original packaging. We will not allow returns on damaged or incomplete products. Proof of purchase is required. Should the product not be in original condition, please contact us before returning it as this may save you some unnecessary costs.

Damaged / Faulty Goods
If you find that the goods were damaged in transit or were faulty in some manner, please contact us within 24 hours of receiving the goods. We will organise for the return of the goods and arrange a credit towards your next purchase or send a replacement product. Customer will incur the cost of return postage and be credited the purchase price only. We recommend that you return your unwanted items using registered post or trackable courier. We can not be held responsible if returned items are lost in transit.

Warranties
Product warranties are governed by the respective manufacturers and / or suppliers warranty terms and conditions (available on request). We will not be liable to you or any third party for any loss suffered due to product failure. We will process product warranty claims through the respective manufacturers and/or suppliers. All warranties are void if the product is not installed by a licensed electrician.

Amp 32A
Colour Grey
Type Socket Outlet
Voltage 500V AC
Material Polycarbonate (Cover)
Frequency 50Hz
Standard AS/NZS 3112
Poles 3P + N + E
Range Clipsal 56 Series
Pin Number 5 Pins
Shape Of Pin Round
PRODUCT INFO
SKU CL56SO532LE-GY
Model # 56SO532LE-GY
Barcode # 9311554203740
Brand Clipsal
SHIPPING INFO
Shipping Weight 0.3330kg
Shipping Width 0.100m
Shipping Height 0.078m
Shipping Length 0.098m
